s Top Supplying Heat Sink Aluminum Extrusion Profile with Industry Standard Thickness
Product Details:
| Place of Origin: | Anhui, China |
| Brand Name: | SHENGXIN |
| Certification: | ISO9001 ISO14001 |
| Model Number: | SX-1202007 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 tons |
|---|---|
| Price: | $3,000.00/tons 5-9 tons |
| Payment Terms: | T/T,L/C,D/P D/A |
|
Detail Information |
|||
| Warranty: | 5 Years | After-sale Service: | Online Technical Support, Free Spare Parts |
|---|---|---|---|
| Alloy Or Not: | Is Alloy | Secondary Or Not: | Non-secondary |
| Project Solution Capability: | Graphic Design, 3D Model Design | Application: | Industry |
| Design Style: | Modern | Product Name: | Aluminum Extrusion Profile |
| Material: | Aluminum Alloy | Color: | Electrophoretic |
| Max Size: | 350mm | Standard: | GB5237-2008 |
| Thickness: | 0.8-3mm | Length: | Customer's Demand |
| Surface Treatment: | Anodizing/Powder Coating | MOQ: | 1 Ton |
Product Description
PRODUCT PARAMETERS
| Business Trip | Manufacturer/OEM/ODM |
| Alloy&Temper | AL 6063 T4/T5/T6 or as customer’s requirement |
| Designs and Tolerances | As per drawings/samples,or re-design as requested or market needs.Tolerance will be shown on each drawing |
| Size | 1.Round Tube(Max Dia:180mm) |
| 2.Square Tube(Max:140mmX140mm or 240mm) | |
| 3.Max width:260mm | |
| Moulds/Dies | Making moulds and producing as per designed drawing |
| 1. Using our existing moulds,no extra charge | |
| 2. Using client drawings,opening mould,actually about 10tons the moulding fee is free | |
| 3. Moulding fee will be by return when order arrived to fixed quantity | |
| Surface Treatment | Powder coating,Anodized,Wooden grain, Polishing,Electrophoresis,Brushed,PVDF,Sanding blasting etc. |
| Application | Aluminum tubes/pipes,Aluminum profiles for Doors,Aluminum profiles for windows,Aluminum profiles for curtain wall,Thermal break aluminum profiles,Industrial aluminum profiles,Heat sink,Solar frame,Aluminum profiles for kitchen cabinet,Aluminum profiles for wardrobe,Aluminum profiles railing,Aluminum profiles for furniture,Aluminum profiles for office partition,Aluminum roller shutter,Aluminum tile trim,Sun room aluminum profiles,Shower room aluminum profiles etc. |
| Length | ≤7.5meters |
| Wall Tickness | ≥0.7mm |
| Further Process Ability | Drilling,Bending,Welding,Precise cutting,punching, fabrication of finished products etc. |
| Certificate | ISO9001;ISO14001 |
| Standard&Warranty | 1. GB5237-2008 equal to EN12020-1.2(2001); 2. Within 10 years without surface quality problem |
| Packing | 1.Inside 1st layer:protective sticky film with or without logo,peal foam interval between each profile,poly bag for each profile etc. |
| 2.Outside 2nd layer:shrink film,single wrapping film,kraft paper,waterproof paper etc. | |
| Price System | Usually we adopt one day one price system.Price will be updated on shanghai metal price(http://www.smm.cn/). |
| Trade Terms | FOB WUHU OR FOB SHANGHAI, EX-WORKS,CFR,CIF,ETC. |
| Payment Terms | 1. L/C at sight 2. 2.T/T 30% deposit,70%balance against of B/L copy 3.D/P at sight 15-30 days |
| Lead Time of Goods | 15-30days |
| Lead Time of Moulds | 7-15days |
| Container Type | 20FEET GP 40FEET GP 40FEET HC 45FEET HC |
| Minimum Order Quantity | 1X20GP FOB CHINA for FCL or 5 TONS EX HUANCHENG WAREHOUSE for LCL |
| Origin | ANHUI,CHINA |
Chemical Composition of Aluminum Profile
| Alloy | Si | Mg | Fe | Cu | Mn | Zn | Cr | Ti | Impurity | Ai | |
| Unit | Total | ||||||||||
| 6063 | 0.2-0.6 | 0.45-0.9 | <0.35 | <0.1 | <0.1 | <0.1 | <0.1 | <0.1 | <0.05 | <0.15 | Surplus |
| 6061 | 0.4-0.8 | 0.8-1.2 | <0.7 | <0.15-0.4 | <0.15 | <0.25 | 0.04-0.35 | <0.15 | <0.05 | <0.15 | Surplus |
| 6060 | 0-0.6 | 0.35-0.6 | 0.1-0.3 | ≤0.1 | ≤0.1 | ≤0.15 | ≤0.05 | <0.1 | <0.05 | <0.15 | Surplus |
| 6005 | 0.6-0.9 | 0.4-0.6 | 0.35 | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 | 0.05 | <0.15 | Surplus |
Surface Treatment
| Class | Min-average film thickness | Min-part film thickness |
| AA10 | 10 | 8 |
| AA15 | 15 | 12 |
| AA20 | 20 | 16 |
| AA25 | 25 | 20 |
(The anodized of goods is generally supplied in grade AA10 or is controlled according to client’s request.)
Electrophoresis Surface Treatment
| Class
| Anodizing | Paint film | Composite film | |
| Min-average film thickness(um) | Min-part film thickness(um) | Min-part film thickness(um) | Min-part film thickness(um) | |
| A | ≥10 | ≥8 | ≥12 | ≥21 |
| B | ≥10 | ≥8 | ≥7 | ≥6 |
| (Electrophoresis coating profiles is generally supplied by Class B,but also supply other levels according to customer’s requirement.) | ||||
We have the molds for the following countries: Nepal, Algeria, Turkmenistan, Mauritius, Libya, Ukrane, Somalia, Cameroon, Ethiopia, Bosnia and Herzegovina, Ireland, Tunisia, Chile, Peru, Columbia, Argentina,Brazil, Bolivia, Philippines, India,Lebanon,Australia,Tunisia,Ecuador,Paraguay,Venezuela
Advantage(compare to most of other Chinese factory):
Lower labor cost, Lower land cost,
Lower tax cost, because we are in China local city, and the larggest enterprise in my city, supported by local govement.
Q: Are you a trading company or manufacturer ?
A: We are a manufacturer with OEM/ODM service.
Q: How do I order your products?
A: If you would order our products,please contact us,we will pay a timely attention to you.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
...
